Place of Origin: | China |
---|---|
Brand Name: | AllWin |
Certification: | ISO9001 |
Model Number: | SP50 SP60 |
Minimum Order Quantity: | 1-5sets |
Price: | USD4000--USD19800/set |
Packaging Details: | Wooden boxes |
Delivery Time: | 20-30 Working Days |
Payment Terms: | T/T, MoneyGram, Western Union |
Supply Ability: | 30sets /month |
Power: | 37kW | Voltage: | 380V |
---|---|---|---|
Litre: | 60Litr | Inner Chamber Material: | SUS 304 |
Explosion: | Explosion Proof | Production Capacity: | 300-800kg/h |
Color: | White | Feed Pump: | 1" ARO Diaphragm Pump |
Mechanical Seal: | Independently Technology | Grinding Beads: | 1.2-1.4mm |
Highlight: | 37kW SC Bead Mill Machine,Paint 60L Bead Mill Machine,60L paint grinding machine |
High Capacity In Paint Pigment Pesticide SC Micron 37kW 60L Bead Mill Machine For Oil Base Ex-Proof
The main introduction of Bead Mill Machine:
1. High independent technology: This Sand grinding mills are main consists of chamber and disc dispersing system. The double end mechanical sealing with independent technology could resistant to more than 1600 kinds of solvents.
2. Urtra fineness: The series have great flow rate and super fine discharging, the finally fineness can be reach 1um for D90 .
3. Better Cooling system:The cooling efficiency is better than normal mills because the sectional double spiral water course is more beneficial to heat exchange.
4. High Efficiency: The grinding efficiency is higher 15-30% than traditional mill machines; the combined disperser can rapidly increase dispersing efficiency.
5. Different materials chosed for inner chamber and dispersing discs: All the materials of contact parts could be chose from wearable steel, stainless steel, PU and ceramics for meeting different requirements.
6. Bigger and Smaller grinding media for different needs: The grinding media is extremely from 0.3-3.0mm are suitable for this series mills. We recommend the 95% zirconium beads. The discharging is great flow with bigger screen rings which can be easily cleaned and removed.
7. Widely application used: This Super series are widely used in coating and paint, pigment, pesticide and agro-chemical industry, Pigment and dyestuffs, Printing inks, Gravure inks, food and food processing,non-metallic minerals.
The Technical Data of Bead Mill Machine:
No | main parameters | SP50 | Note |
1 | Non Explosion-proof motor kW | 30kW (Non Ex) | |
2 |
Effective volume of grinding chamber (L) |
50 | |
3 | Water pressure (MPa) | 0.3 | |
4 | Cooling water consumption (L/min) | 2.5 -3m3/h | Advise offer the Cooling water less 10°C |
5 | Dimensions:L*W*H (mm) | 1940*900*2000 | |
6 | Weight (kg) | 1500 |
The Configuration instructions of Bead Mill Machine:
1. Outer chamber materials: 304 stainless steel
2. Inner Chamber materials: 304 stainless steel or you need
3. Dispersing shaft: 40Cr with hard chromium plating
4. Dispersing disk: PU coated 304 stainless steel
5. Feeding and discharging end covers on the cylinder: 304 stainless steel
6.Turbine centrifugal separator and pins: 304 stainless steel and YG6 pins
7. Static discharge screen ring: Wire Wound screen ring with 304.Gaps: 0.5mm.
8. Mechanical seal: Intelligent double mechanical seal with indepent technology
9. Feeding pump: 1.5” ARO diaphragm pump;
10. Appliance configuration: Non Explosion-proof machine, suitable for water base materials, motor 55kW. Non Explosion-proof parts: operation column,electrical appliance boxes;electric contact pressure gauge, temperature,solenoid valves with NO ex electrical contacts., Control system (button type).
11. Fasteners and connecting parts: Stainless steel clamp-type connecting parts.
This series from 5L to 300L
"SUPER" SP series of Bead Mill | ||||
Type |
Working Volume (L) |
Power (kW) |
Grinding Beads (mm) |
Throughput (kg/h) |
SP5 | 5 | 7.5 | 0.3-3.0 | 20-200 |
SP15 | 15 | 15 | 0.3-3.0 | 50-500 |
SP30 | 30 | 30 | 0.3-3.0 | 70-700 |
SP50 | 50 | 37 | 0.3-3.0 | 100-1000 |
SP100 | 100 | 55 | 0.3-3.0 | 300-3000 |
SP250 | 250 | 75 | 0.3-3.0 | 450-4500 |
SP300 | 300 | 90 | 0.3-3.0 | 550-5500 |
Long history and plentiful experiences with 25 year
Master the core technology of dispersing and grinding
With imported four –axis Haas machining center
Have laboratory for grinding test and detection the fineness.
With ISO9001 certification and more than 11 patents of sand mill
Widely used in industries : Paint and Coating ,Pigment and dyestuffs, Printing inks, Gravure inks, Medicine and Cosmetics, food and food processing, Pesticide and Agrochemical industry, Hi-Tech nanometer products.
The After sales service:
1. Video instructions for installation and commissioning, if need, we will arrange engineer to your factory.
2. 12-24H feedback any customers questions, firstly offer the video help you solving, if need arrange maintenance engineer for you.
The packing and delivery (firstly anti-abrasion film and packed in wooden boxes)
If need more detailed information and price ,please contact us soon and warmly welcome to visit us!
