50L Wet Horizontal Bead Mill SIC Bead Grinding Machine White Products

Basic Information
Place of Origin: China
Brand Name: AllWin
Certification: ISO9001
Model Number: SP50 SP100
Minimum Order Quantity: 1 Unit
Price: USD20000---25000/unit
Packaging Details: Wooden boxes
Delivery Time: 20-30 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 50 units /month
Detail Information
Volume: 50litre Power: 37kW
Materials: SIC Warranty: 12 Months
Explosion: EX-proof Used Field: Pesticide SC, Oil, Paint,Food Process
Saving Engery: 10-20% Mechanical Seal: Independent Technology
Grinding Type: Dispersing Disc Operation Control: Button Type Control
Temperature Control: Lower At Least 55-10 Degrees Than General Mills(decreased Temperature Is Different From Materials)
High Light:

50L Wet Horizontal Bead Mill


button SIC Horizontal Bead Mill


button SIC bead grinding machine

Product Description

50L Wet Horizontal Bead Mill SIC Bead Grinding Machine White Products
The main introduction of Bead Mill Machine
1. The structure is compact and stable: the motor is placed on the upper part, the grinding chamber is placed on the lower part, and the total height of the equipment is low. More than 20L large model mills with chamber slide rail for easy maintenance.
2. Double mechanical seal: It has 2 patented technologies, with forced coolant, sealing ring resistant to 1600 kinds of solvents, coolant is compatible with materials, no pollutants, and reliable operation.
3. Discharge separation system: Large flow, no blocked: dynamic hollow rotor-super large area slot separator uses dynamic centrifugal force separation principle. Use of extremely small grinding beads (0.6-1.8).No export blockage occurs under high flow conditions. Good heat dissipation, narrowest particle size distribution.
4. Classic disc dispersing: 3 side discs, 4 side discs, curved discs, lumbar discs and eccentric discs, different materials can be selected, such as stainless steel, alloy steel, ceramic, hard alloy &PU etc.


The main parameter
      1. Explosion proof motor: 37 kW 380V 50HZ
      2. Effective volume of grinding chamber: 50L
      3. Water pressure(Mpa): 0.3
      4. Cooling water consumption: 2.5 -3m3/h
      5. Dimension (L*W*H): 1900*900*1900mm
      6. Weight: 1.5T

The main struture  information:
No Main parts SP50 Ex-proof Notes
1 External vessel 304 stainless steel
2 Inner grinding vessel Silicon Carbide Ceramics
3 Dispersing shaft 40Cr with hard chromium plating

Dispersing disk

(agitator disk)

 304 stainless steel,
5 Feeding and discharging end covers on the cylinder 304 stainless steel
6 Static discharge screen ring Wire Wound screen ring with 304.Gaps: 0.5mm.
7 Mechanical seal

Intelligent double mechanical

seal with mandatory

lubricating-cooling system

8 Feeding pump 1” ARO diaphragm pump;






Appliance configuration Explosion-proof machine, suitable for water base materials, motor 15kW. Explosion-proof parts: operation column,electrical appliance boxes;electric contact pressure gauge, temperature,solenoid valves with NO ex electrical contacts., Control system (button type)
10 Fasteners and connecting parts

Stainless steel clamp-type

connecting parts

Quick and convenient
The detailed production show:
50L Wet Horizontal Bead Mill  SIC Bead Grinding Machine White Products 0
50L Wet Horizontal Bead Mill  SIC Bead Grinding Machine White Products 1

The Packing and Shipping: Be covered with anti-abrasion film and then packed in plywood cases. then sea shipping by FCL or LCL.
After sales service:

1. Video instructions for installation and running test, if need, we will arrange engineer to your factory.

2. 12-24H feedback any customers questions, firstly offer the video help you solving, if need arrange maintenance engineer for you.

The Culture of ALLWIN company
Company Target: to be a better service-provider and manufacturer in grinding and dispersing.
Product Mind: to produce great machines for great enterprises which are facing future, starving to development.

Service Aim: to creat values for user-centered customers.
Cooperation Principle: to solve the problem with mutual benefits.

Q1: Are you a trading company or manufacturer?
A1: We are the manufacturer.
Q2: Where is your company and factory located? How can I visit you?
A2: Our company is located in Tongxing industrial zone in Caijia Town, Beibei, Chognqing, China. Post code: 400709. It takes about 0.5 hours from Airport to our coampny by car. All our potential clients, from home or abroad, are warmly welcomed!
Q3: Do you have own R&D team?
A3: Yes, we have 12 engineers, and our products could be customized for your requirements.
Q4: How about the quality?
A4: We have professional engineers and a strict QA& QC system, Our factory comply with the IS09001 standard strictly.
Q5: What is your after-sale service?
A5: we offer 100% guarantee on our product and agree 1:1 replace defective products. Firstly we offer the video instruction for maintenance for you ,if need ,we will arrange engineer for you.
Q6: How is the payment?
A6: Firstly paid the deposit, then paid the balanced before shipping.
Q7: How is the package and delivery?
A7: Normally are the wooden boxes, and FCL or LCL container for sea shipping.
If need more detailed information and price , please don't hesitate contact us, Also Warmly welcome to visit us.
