| Place of Origin: | China |
|---|---|
| Brand Name: | AllWin |
| Certification: | ISO9001 |
| Model Number: | JF45 |
| Minimum Order Quantity: | 1set |
| Price: | 2500USD-9800USD |
| Packaging Details: | Naked or Wooden boxes |
| Delivery Time: | 20-30 working days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 30sets /month |
| Power: | 45 KW | Explosion: | EX Proof |
|---|---|---|---|
| Color: | White | Diameter Of Impeller: | 450mm |
| Weight: | 1T | Size: | 2300*800*2300mm |
| Centre Distance: | 1100 | Lifting Type: | Hydraulic Lifting |
| High Light: | Liquid High Speed Disperser,45kW High Speed Disperser,45kW Liquid high speed agitator |
||
Industrial Liquid Dispersion Paint,Ink Chemical,Paper Making 45kW High Speed Disperse
The series of JF high speed dispersing machine( mixer machine ) are suitable for producing paint, ink, coating, dyestuff, paper making, etc... in chemical industry. The mixers are used for wet dispersing and mixing liquid-solid material. On-grade speed adjustment by frequency converters, with hydraulic lifting, safety and steady work, better dispersing effect, easy maintenance.
Main characteristics of JF45 High speed disperser:
1. Allwin’s proprietary technologies: Thress securities for vertical column with hydraulic lifting:No oil leakage, no ceiling-hitting and rotary 360°for machine frame.
2. 40Cr hard chrome-plated.
3. Converter built-in Electrical box, not explosion-proof far away from the scene, with explosion-proof motor and explosion-proof operation column
4. Color:White or blue
5. Hydraulic lifting, safety and steady work.
6. Better dispersing effect and easy Operation and low maintenance.
Main parameter of High Speed disperser:
| Model/parameter | JF2.2 | JF5.5 | JF7.5 | JF11 | JF15 | JF18.5 | JF22 | JF30 | JF37 | JF45 | |||
| Main motor | kw | 2.2 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 | ||
|
Diameter of impeller |
mm |
130/150 |
200/250 |
200/250 |
250/300 |
250/300 |
330/350 |
330/350 |
400 |
400 |
450 |
||
|
Rotary speed |
R/min | 0-1450 | 0-1800 | 0-1800 |
0-1500
|
0-1500
|
0-1500
|
0-1500
|
0-1200
|
0-1200
|
0-1000
|
||
| centre-to-centre distance | mm | 550 | 845 | 845 | 900 | 900 | 935 | 935 | 1100 | 1100 | 1100 | ||
| Lifting travel | mm | 600 | 900 | 900 | 1000 | 1000 | 1100 | 1100 | 1300 | 1300 | 1300 | ||
| Pump motor | kw | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 | 1.1 | 1.1 | 1.1 | ||
| Total height | mm | 1200 | 1700 | 1700 | 1900 | 1900 | 2000 | 2000 | 2300 | 2300 | 2300 | ||
| Rotary angle of main frame |
|
±180° | ±180° | ±180° | ±180° | ±180° | ±180° | ±180° | ±180° | ±180° | ±180° | ||
| Overall dimension | A | mm | 1200 | 1380 | 1380 | 1700 | 1700 | 1820 | 1820 | 2300 | 2300 | 2300 | |
| B(width) | mm | 400 | 650 | 650 | 650 | 650 | 650 | 650 | 800 | 800 | 800 | ||
| L | mm | 550 | 650 | 650 | 900 | 900 | 935 | 935 | 1100 | 1100 | 1100 | ||
| H1 | mm | 1200 | 1700 | 1700 | 1900 | 1900 | 2000 | 2000 | 2300 | 2300 | 2300 | ||
| H2 | mm | 1250 | 1250 | 1520 | 1520 | 1520 | |||||||
| h1 | mm | 300 | 300 | 300 | 300 | 300 | 300 | 300 | 300 | 300 | 300 | ||
| h2 | mm | 600 | 600 | 725 | 725 | 725 | |||||||
The customers workshop
After sales service:
1. Video instructions for installation and commissioning, if need, we will arrange engineer to your factory.
2. 12-24H feedback any customers questions, firstly offer the video help you solving, if need arrange maintenance engineer for you.
FAQ:
Q1: Are you a trading company or manufacturer?
A1: We are the manufacturer.
Q2: Where is your company and factory located? How can I visit you?
A2: Our company is located in Tongxing industrial zone in Caijia Town, Beibei, Chognqing, China. Post code: 400709. It takes about 0.5 hours from Airport to our coampny by car. All our clients, from home or abroad, are warmly welcome to visit us!
Q3: Do you have own R&D team?
A3: Yes, we have 12 engineers, and our products could be customized for your requirements.
Q4: How about the quality?
A4: We have professional engineers and a strict QA& QC system, Our factory comply with the IS09001 standard strictly.
Q5: What is your after-sale service?
A5: we offer 100% guarantee on our product and agree 1:1 replace defective products. Firstly we offer the video instruction for maintenance for you ,if need ,we will arrange engineer for you.
Q6: How is the payment?
A6: Firstly paid the deposit, then paid the balanced before shipping.
Q7: How is the package and delivery?
A7: Normally are the wooden boxes, and FCL or LCL container for sea shipping.
If need more detailed information and price ,please contact me and warmly welcome to visit us.
